Lab RF Test Cable Assembly

The Lab RF Test Cable Assembly is engineered for precision high-frequency measurements and signal transmission in laboratory environments. Designed with superior flexibility and high bend life, it maintains excellent phase stability and low loss during repeated operations. With high-density braided shielding and lightweight construction, it is ideal for benchtop instruments, vector network analyzers, oscilloscopes, and signal generators. Supporting a frequency range up to 50 GHz and multiple connector types (SMA, 2.92 mm, 3.5 mm, N-type, etc.), it provides reliable and durable RF interconnections for laboratory test setups.

Product Description

Characteristics & Advantages

Excellent mechanical phase stability
Excellent mechanical amplitude stability
Excellent shielding performance
Excellent durability
Highly reliable structure
Stainless steel connector housing

Product Description

This series of cable assemblies is mainly designed for applications with strict requirements for mechanical amplitude and phase. Its insulation layer adopts a low-density PTFE winding structure, and the shielding layer has three layers of protection: silver-plated copper tape braided, high—temperature aluminum foil and silver-plated copper wire braided, ensuring excellent mechanical stability. All products adopt highly reliable structures and stable and consistent processes, which can meet various application scenarios of military customers.

Application
